| Code | diameter Tube | fillet steak | internal hole fitting |
mm | BSPT | mm | |
SCG-3M-4G | 3 | 1/4" | 2.4 |
SCG-6M-4G | 6 | 1/4" | 4.8 |
SCG-6M-6G | 6 | 3/8" | 4.8 |
SCG-6M-8G | 6 | 1/2" | 4.8 |
SCG-8M-4G | 8 | 1/4" | 5.5 |
SCG-8M-6G | 8 | 3/8" | 6.5 |
SCG-8M-8G | 8 | 1/2" | 7.0 |
| SCG-10M-4G | 10 | 1/4" | 5.5 |
| SCG-10M-6G | 10 | 3/8" | 6.5 |
| SCG-10M-8G | 10 | 1/2" | 7.0 |
| SCG-12M-4G | 12 | 1/4" | 5.5 |
| SCG-12M-6G | 12 | 3/8" | 6.5 |
| SCG-12M-8G | 12 | 1/2" | 7.0 |
SCG-20M-8G | 20 | 1/2" | 7.0 |
| SCG-22M-8G | 22 | 1/2" | 7.0 |
