Code | diameter Tube | fillet steak | internal hole fitting |
mm | NPT | mm | |
| STBF-6M-2N | 6 | 1/8" | 4.8 |
| STBF-6M-4N | 6 | 1/4" | 4.8 |
| STBF-6M-6N | 6 | 3/8" | 4.8 |
| STBF-6M-8N | 6 | 1/2" | 4.8 |
| STBF-8M-2N | 8 | 1/2" | 6.4 |
| STBF-8M-4N | 8 | 1/4" | 6.4 |
| STBF-8M-6N | 8 | 3/8" | 6.4 |
| STBF-8M-8N | 8 | 1/2" | 6.4 |
| STBF-10M-2N | 10 | 1/8" | 7.9 |
| STBF-10M-4N | 10 | 1/4" | 7.9 |
| STBF-10M-6N | 10 | 3/8" | 7.9 |
| STBF-10M-8N | 10 | 1/2" | 7.9 |
| STBF-12M-4N | 12 | 1/8" | 9.5 |
| STBF-12M-6N | 12 | 3/8" | 9.5 |
| STBF-12M-8N | 12 | 1/2" | 9.5 |
| STBF-16M-8N | 16 | 1/2" | 12.7 |
