Chemical hoses

RUBBER HOSE BI.BLUE/60 DIELECTRIC

Download sheet in pdf format

Description and technical data

Dielectric EPDM rubber hose with textile inserts. Blue fabric-finish cover. White, non-conductive interior. ALSO KNOWN AS PIEDMONT HOSE.
Applications: pipe particularly suitable for induction furnaces, steelworks, glassworks, for the delivery of pressurized water and low concentration acid and alkaline solutions
Operating temperature: -40°C to +100°C peaks of 120°C.
Dielectric strength >5000 V/mm.
Safety factor three for burst pressure.


Code Dimensions Ø mm Curvature radius mm Working pressure bar Theoretical weight Kg/m
10GBIBLU6009/16 9x16 50 25 0.21
10GBIBLU6012/21 12x21 70 20 0.29
10GBIBLU6015/23 15x23 90 20 0.37
10GBIBLU6015/25 15x25 120 20 0.43
10GBIBLU6019/30 19x30 120 20 0.52
10GBIBLU6022/30 22x30 180 15 0.40
10GBIBLU6025/34 25x34 200 15 0.50
10GBIBLU6030/42 30x42 240 15 0.82
10GBIBLU6038/52 38x52 280 20 1.10
10GBIBLU6040/54 40x54 300 20 1.20
10GBIBLU6045/60 45x60 340 15 1.45
10GBIBLU6050/68 50x68 330 15 2.00
10GBIBLU6060/78 60x78 480 15 2.40
