ACQUAFLAT-M BLUE PVC HOSE 10/8 bar

ONLINE CATALOGUE  ›  HOSES  ›  Flattenable tubes

ACQUAFLAT-M BLUE PVC HOSE 10/8 bar


Download sheet in pdf format

Flexible PVC hose with flattenable structure.

Smooth black interior, smooth abrasion resistant blue exterior.

Small dimensions that facilitate transport and use.

Suitable for delivery at medium pressures.

Operating temperature:-10°C to +60°C.

50 METER ROLLS












Code OR

mm		 Weight

g/m		 Pressure
of exercise
Bar		 Pressure
of explosion
bar		 Rolls

meters
04PACQ0000020 5 20 150 10 30 50
04PACQ0000025 5 25 160 10 30 50
04PACQ0000030 5 30 170 8 30 50
05PACQ0000032 5 32 170 8 30 50
04PACQ0000035 5 35 200 8 30 50
04PACQ0000040 5 40 250 8 30 50
04PACQ0000045 5 45 280 8 30 50
04PACQ0000052 5 52 320 6 30 50
04PACQ0000060 5 60 420 6 24 50
04PACQ0000063 5 63 420 6 24 50
04PACQ0000076 5 76 500 6 24 50
04PACQ0000080 5 80 650 6 24 50
04PACQ0000102 3 102 750 6 24 50
04PACQ0000127 5 127 1000 5 15 50
04PACQ0000153 5 152 1200 4 12 50
04PACQ0000204 5 204 2300 4 9 50
