RUBBER HOSE HEAT/10 bar
ONLINE CATALOGUE › HOSES › Hot water hoses
Download sheet in pdf format
Construction: Heat-resistant EPDM synthetic rubber, synthetic textile reinforcements, aging- and weather-resistant EPDM synthetic cover. Appearance: Smooth black exterior with a canvas finish, smooth black interior.
Use: Pipe suitable for the passage of hot water, even mixed with steam, and antifreeze liquids, in car radiators, engine cooling systems, heating circuits of vehicle cabins, and fluids with medium chemical aggressiveness.
Operating temperature: -40°C +120°C.
Maximum continuous working pressure: 10 BAR, safety factor 3.
Rolls of 40-61 meters.
Use: Pipe suitable for the passage of hot water, even mixed with steam, and antifreeze liquids, in car radiators, engine cooling systems, heating circuits of vehicle cabins, and fluids with medium chemical aggressiveness.
Operating temperature: -40°C +120°C.
Maximum continuous working pressure: 10 BAR, safety factor 3.
Rolls of 40-61 meters.
| item | OR |
|---|---|
| 09GCAL010/020 T | 10x20 |
| 09GCAL012/022 T | 12x22 |
| 09GCAL013/023 T | 13x23 |
| 09GCAL015/025 T | 15x25 |
| 09GCAL016/026 T | 16x26 |
| 09GCAL018/028 T | 18x28 |
| 09GCAL019/029 T | 19x29 |
| 09GCAL020/030 T | 20x30 |
| 09GCAL025/035 T | 25x35 |
| 09GCAL030/041 T | 30x41 |
| 09GCAL032/042 T | 32x42 |
| 09GCAL032/044 T | 32x44 |
| 09GCAL035/047 T | 35x47 |
| 09GCAL038/052 T | 38x50 |
| 09GCAL042/054 T | 32x54 |
| 09GCAL040/054 T | 40x54 |
| 09GCAL045/061 T | 45x61 |
| 09GCAL050/068 T | 51x67 |
| 09GCAL060/075 T | 60x75 |
| 09GCAL060/082 T | 60x82 |
